Union JH604 PowerLOAD 98mm Lift Off Hinge BZP

Product code: Select Options

Select Options
x
Inverness Depot30
From £6.76 (£5.63 +VAT)
Delivery Truck Logo

£6.95

Or Free Collection From Store

Union 604 PowerLOAD Journal Support Lift-off hinge suitable for heavy duty applications
and for use on doors which are subject to a high frequency of use by the public with little incentive to exercise care.

Available in LEFT hand (clockwise closing - Shown in picture & diagram) or RIGHT hand(anti-clockwise closing).

Bright Zinc Plated finish.

These hinges are sold as singles - NOT pairs.

A datasheet can be downloaded from the link below.

Union 604 datasheet
  • Type
Type:Select

Quantity:

  • Suitable for 80kg door mass (door mass to include adjustment for door closers, furniture and environmental conditions)
  • 180º angle of opening
  • Radius corner offers speed of fixing with machine tools
  • Lift-off feature enables easy removal of door for maintenance
  • Bright zinc plate finish in mild steel variant
  • Phosphorus bronze bushes. Self lubricating, low friction maintenance free bearings
  • Congruent fixing pattern - spreads the load of the door more effectively within the timber
  • 98mm
  • Sold as single hinge
  • EN1935:2002 performance tested to 200,000 cycles on 80kg door mass
  • Included in fire test to BS EN 1634-1 with assessment for use on timber fire doors with intumescent protection up to FD30 and FD60 provided they are fitted in accordance with the guidelines detailed in IFCA/06252
