Union 22EU Euro Profile Cylinder Sashlock

Product code: Select Options

Select Options
x
Kirkwall Depot10
Inverness Depot13
Elgin Depot18
From £22.51 (£18.76 +VAT)
Delivery Truck Logo

£6.95

Or Free Collection From Store

Union 22EU Euro Sashlock case.

For timber doors hinged on the left or right.
Suitable for doors up to 54mm thick.
Easily reversible radius latch that uses the unique UNION SwitchLatch technology
No tools are needed, it's Time saving and Simple
Anti rattle adjustable strike for on site fine tuning.

A Datasheet can be downloaded from link below.

Union 22EU sashcase datasheet
  • Finish
  • Size
Finish:Select
Size:Select

Quantity:

  • Case Size: 68mm (2.5') or 81mm (3')
  • Backset: 45mm or 57mm
  • Case: Steel, red powder coat
  • Forend: Stainless steel or brass plated
  • Striking Plate: Finished to match forend
  • Faceplate: Supplied with square faceplate which covers a radius inner forend
  • Deadbolt: Zinc with hardened steel rollers
  • Latch Bolt: Zinc
  • Follower: Sintered Steel
  • Rebate Kit: 2200REB 13mm (0.5')
  • Suitable for use on 30 and 60 min fire doors
  • For timber doors hinged on the left or right
  • Suitable for doors up to 54mm thick
  • For use with an euro profile cylinder
  • Easily reversible radius latch that uses the unique UNION SwitchLatch technology, No tools are needed, it's Time saving and Simple
  • Anti rattle adjustable strike for on site fine tuning
  • Radius plastic splinter guard for easy installation and a professional finish
  • Anti-saw security features for resistance against attack
  • Chamfered bolt design increases the performance of the lock under side load testing.
  • Radius inner forend for ease of installation
  • Deadbolt locked or unlocked by the cylinder key or turn
  • 14mm deadbolt for secure positive deadlocking
  • Can be installed in the many UK mortices without the need for additional carpentry or spoiling the edge of the door
  • Hardened steel pins provide resistance to attack from sawing
