Union HD72ESL Heavy Duty Euro Emergency Escape Sashlock
Product code: 12055068
£6.95
Or Free Collection From Store
Union HD72ESL - Heavy Duty Euro Profile Emergency Escape Sashlock.
For use in high frequency areas used by public or others with little incentive to exercise care and with a high chance of misuse.
Lever operation from the inside retracts both the latchbolt AND the deadbolt.
Giving free egress with one hand operation.
Ideal for use in hotel and B&B bedroom doors or other public use room doors.
European DIN style casing with 72mm centres and 60mm backset for use with Euro-profile cylinders.
Heavily sprung latch follower allows use of heavy unsprung door furniture (weighing up to 930g per pair).
Note: For BS EN 179 compliance only J-1000RRS01 and J1000RRU01 can be used.
Durable latch follower technology successfully cycle tested to 3.5 million operations.
20mm Single throw deadbolt for ease of operation.
Quick reversible latch allows easy on-site handing.
Split follower - Escape side changeable on site.
Cylinder to latch functionality.
Quantity:
| Furniture: | For use with sprung or unsprung door furniture |
| Angle of lever operation: | 35° |
| Cylinders: | Euro profile, single, double or cylinder and thumbturn |
| Fixings: | Accepts 38mm centre bolt through door furniture |
| Handing: | Easily reversible for left and right hand |
| Backset: | 60mm |
| Follower: | 8mm reversible split follower, supplied complete with split spindle |
| Lockcase depth: | 90mm |
| Height: | 165mm |
| Lockcase Thickness: | 16mm |
| Centre Distance: | 72mm |
| Inner Forend: | Radius |
| Outer forend/Strike: | Square |
| Forend size: | 235mm (L) x 24mm (W) |
| Deadbolt throw: | 20mm single throw |
| Latch & Deadbolt material: | Steel chrome plated |
| Case material: | Heavy duty mild steel enclosed case. Silver finish |
| Faceplate & Strike material: | Grade 304 Satin Stainless Steel |
| Splinter box: | Black plastic |
- Escape Sashlock function from the inside
The latch and deadbolt are retracted simultaneously with a single operation of the lever handle
When unlocked only the latch is retracted
Deadbolt locked and unlocked by the cylinder key/cylinder turn
On a second turn the cylinder will retract the latchbolt
Escape Sashlock function from the outside
Only the latch bolt is withdrawn by lever handle
Deadbolt locked and unlocked by the cylinder key/cylinder turn
On a second turn the cylinder will retract the latch head
- Tested to BS EN12209
-
CE Marked and fully tested to EN 12209 2003 Grade 3 category of use:
High frequency of use by public or others (i.e. members of the public, students and employees etc.) with little incentive to exercise care - CE Marked, Suitable for use on fire doors
- Tested to EN 1634-1 2014 on 30 and 60 minute timber fire doors and 240 minute metal fire doors
- For 30 and 60 min fire doors use 1mm interdens behind the strike plate and 2mm interdens around the lockcase
- Certifire approved: CF5543
- BS EN 12209 Classification: 3X810G1BB20
- BS EN 12209 CE Cert No: 0086-CPR-658456
- 15 year guarantee: The performance of the HD72 is supported by a 15 year guarantee
- Equality Act: The dimensions of the lock case assist in fulfilling requirements and duties required under the Equality Act by satisfying the recommendations of BS 8300 2009 and Approved Document M 2015 (2016)
